The 6206 ZZ C3 is a deep groove ball bearing with metal shields on both sides (ZZ), designed to protect from larger particles while allowing low-friction rotation. It measures 30 x 62 x 16 mm and is widely used in household appliances, motors, and light industrial machinery. The C3 clearance supports higher speeds and improved durability.
Key Features
- Bearing Type: Deep Groove Ball Bearing
- Shield Type: ZZ (Double metal shields on both sides)
- Internal Clearance: C3 (greater radial play for high-speed or thermal expansion applications)
- Material: High-carbon chromium steel
- Lubrication: Factory pre-lubricated with high-performance grease
- Cage: Pressed steel for high strength and reliability
Applications
- Electric motors and pumps
- Gearboxes and transmissions
- Agricultural equipment
- Machine tools
- HVAC systems
- Home appliances
Equivalent Models
- SKF 6206-2Z/C3
- FAG 6206-ZZ-C3
- NTN 6206ZZC3
- KOYO 6206ZZ C3
| SD [mm] | D [mm] | B [mm] | R [mm] | CR1 [N] | COR1 [N] | FO | LG [rpm] | DAM1 [mm] | DA1 [mm] | DA2 [mm] | RA [mm] | MASS [kg] |
| 30 | 62 | 16 | 1 | 19500 | 11300 | 13.8 | 11000 | 35 | 38.5 | 57 | 1 | 0.199 |
